| Optical System | Infinity Corrected Optical System. |
|---|---|
| Stand | Single mold Aluminum stand with hand rests for enhanced comfort and stability. |
| Viewing Body | Siedentopf type Binocular head, 30° inclined, 360° rotatable, Interpupillary distance 48 – 76mm anti fungle, anti bacterial body. |
| Eyepieces | Wide field 10x/22mm eye-pieces with rubber eyecups. |
| Nosepiece | Reverse angle quintuple nosepiece (Ball bearing type) with click stops and rubber grip. |
| Objectives | i series DIN Infinity Plan Achromatic objectives 4x, 10x, 40x (spring loaded), 100x (spring loaded, oil). Antifungal and antireflection coated. Upper limit stopper to protect the objective. |
| Mechanical stage | Rackless X-axis stage, 140 × 150 mm, X/Y travel 76 × 50 mm, right-hand controls, hard-coated surface, double clips, 0.1 mm precision. |
| Condenser | Sub stage Abbe condenser NA 1.25 with aspheric lens. Iris diaphragm with blue daylight filter. Rack and pinion movements on stainless steel guides. |
| Focusing | Coaxial coarse and fine focusing on ball drive system for smooth operation. |
| Illumination | 5W LED Koehler’s illumination with variable illumination control. Up to 100,000 hours of LED life. |
| Electronics | Universal input 100V- 240V AC, 50/60Hz, built-in voltage stabilizer, field diaphram, center adjustable. |
| Accessories | Pointers & Micrometer Reticules, Phase, Polarizing, Fluorescence and Dark Field Kits, Quintuple Nosepiece, Auxiliary Objectives and Eyepieces, Digital Cameras and Adapters, Infinity Plan Optics, Monocular 30 Degree Head |
| Package Contents | Power Cable (5ft), Immersion Oil, Cord Hanger Kit, Spare bulb (20w version only), Nylon Dust Cover & Cleaning Cloth, Styrofoam Casingg, Instruction manual. |
| Certifications | ISO 9001:2015, ISO 13485:2016, European CE, IEC 61010-1,IEC 60601-1:2005,US FDA, GEM |
